SMD2835 LED Module
Power: 1.5W/PCS
Voltage: DC12V
Size: 62mm x 13mm
IP:IP68 waterproof
LED Type: Samsung SMD2835
Total Lumen: 180LM/PCS
Emitting Colour: W. WW R, B, G, Y, P
Colour Rendering Index: RA85
Beam Angle: 160 Degree
Life Span: 50000H
Certification:CE,ROHS,UL
Can print any logo on module if needs
Can print any logo on module if needs
Product Description
● Model:GN-G2035L4
● LED Type:SMD2835
● Chip Brand:Samsung
● Power:1.5w/pcs
● Work Voltage:DC12V
● Waterproof Rate:IP68
● Size:L62*W13*H4mm
● Lumen:180lm/pcs
● LED Quantity:3leds/pcs
● Color for choice:Cool White,Pure White,Warm White,Red,Blue,Green,Yellow,Pink
● Material:ABS housing+Aluminum PCB+Optical Lens
● Beam Angel:160 Degree
● Module Quantity/String:20pcs/string
● Weight:1.2kg/100pcs
● Work Temperature:-40-70 degree
● Warranty:5 years
Features
● Sourced by high output SMD2835, good color conformity and no spot.
● 99.99% gold thread, pure copper bracket coated with silver.
● Constant current driving technology guarantees stable performance of product.
● SDCM≤5 each BIN.
● Special lens design, 160°beaming angle with even light.
● Overmoulded: anti-dusting, anti-moisture, waterproof, anti-shock.
● Ra>85,50,000 hours lifespan
● High quaity 3M tape adhesive at back, with screw holes,easy to install and fix.
● CE, ROHS and UL certified.
Application
● Best for 4-30cm depth illuminate letter or light box at airports, metros, banks, buildings and shopping malls,etc
● Channel Letter light.led signage lighting source and other lighting project
